DocumentLocal Class Reference
Namespace | ohm::flip |
Inherits from | |
Declared in | ohm/flip/DocumentLocal.h |
Overview
The DocumentLocal class implements a simple Flip document with an embedded client and server side. It should be used to quickly test the Flip framework (as in the Babystep Tutorials ) or as a easier way to implement a Flip application without its collaboration-oriented features. The following sections will only document the public API.
Partial Class Diagram
Methods Overview
Constructor
Initing/Restoring
Manipulating Flip Threads
Manipulating
Methods
DocumentLocal constructor
Constructs a DocumentLocal and bind it a DocumentObserver
DocumentLocal (DocumentObserverMaster & observer); |
init
Init a DocumentLocal with the document located on the disk at path as an fopen styled path. If the file pointed by path does not exist, create a blank document with a root class.
void init (); |
create
Creates a Flip thread. Returns a reference to it.
DocumentClientMasterSlot & |
create (DocumentClientMaster & document_master); |
pre_release
Pre-release a Flip thread. All Flip threads must be pre-released before they can be released.
void pre_release (); |
AutoUserInputs class
Implements an automatic way to let know the Flip framework that a transaction begin might occur, or that a transaction comes to its end, and acts as a safe guard.
AutoUserInputs (DocumentBase & document); |
virtual ~AutoUserInputs (); |
Each function that might change the model must be surrounded with an automatic variable of the type of this class. Usually this is done in the top function that handles user inputs or timers.
ListingExample of implementation
void MySystemView::handle_user_inputs (SystemEvent & event) |
{ |
ohm::flip::AutoUserInputs auto_ui (_document); |
switch (event._type) |
{ |
[...] |
} |
} |
Internally, AutoUserInputs will call notify_pre_user_inputs_tasks and notify_post_user_inputs_tasks in its destructor.
notify_pre_user_inputs_tasks
Indicates to the Flip framework that a transaction might start, and acts as a safe guard.
void notify_pre_user_inputs_tasks (); |
notify_post_user_inputs_tasks
Indicates to the Flip framework that any opened transactions must be ended.
void notify_post_user_inputs_tasks (); |
