DocumentBase Class Reference
Namespace | ohm::flip |
Declared in | ohm/flip/private/DocumentBase.h |
Derived Classes | |
Overview
The DocumentBase class implements a Flip document base class. The following sections will only document the public API.
Partial Class Diagram
Methods Overview
Casting
State
Constants Overview
The Controller enum constants are usually used in an observer document_changed call to know what was the source of the model control.
- Controller enum
- Controller_SERVER
- Controller_SELF
- Controller_NETWORK_EXT
- Controller_NETWORK_ACK
- Controller_NETWORK_DENY
- Controller_LOCAL
- Controller_UNDO_REDO
- Controller_DOC_READ
- Controller_DOC_RELEASE
Methods
get_root
Returns the root object.
Object * get_root (); |
template <class T> |
T & get_root (); |
The first version will return a pointer to an ohm::flip::Object .
The second version will return a reference to the root object, as seen as an T type, and will throw if dynamic casting fails.
get_object
Returns the object associated to the Flip reference number ref , or 0 if no object is associated to the Flip reference number ref .
Object * get_object (Ref ref); |
template <class T> |
T * get_object (Ref ref); |
The first version will return a pointer to an ohm::flip::Object .
The second version will return a pointer object, as seen as an T type, and will return 0 if dynamic casting fails.
This function is usually used widely because it is a safe way to keep a reference to an object, as caching Flip object pointers is not safe.
WARNING:Caching a Flip object pointer is not safe. Any developer not following this rule shall be severly punished.
get_controller
Returns the current Controller of the document. The different meaning of those controllers are exposed below.
Controller get_controller () const; |
Constants
Controller
The Controller enum, which is in the scope of the DocumentBase class is exposed below.
Controller_SERVER
Indicates that the source of the model control is the server, that is the transaction was created and issued from the server.
Controller_SELF
Indicates that the source of the model control is the current Flip thread. In particular when only one Flip thread is used, this means that the source of the model control originated from the current client.
Controller_NETWORK_EXT
Indicates that the source of the model control is another client on the Flip network.
Controller_NETWORK_ACK
Indicates that the source of the model control is the server which validated succesfully the client transaction.
Note:this rarely occurs in practice
Controller_NETWORK_DENY
Indicates that the source of the model control is the server which rejected the client transaction, because either the structural validation or logical validation failed.
Controller_LOCAL
Indicates that the source of the model control is issued from the same Flip client, but from another Flip thread. In particular when only one Flip thread is used, this controller value is never set.
Controller_UNDO_REDO
Indicates that the source of the model control is issued from the Flip undo/redo system.
Controller_DOC_READ
Indicates that the source of the model control is the initial read of the document. This is the very first controller used and only one until the document is closed.
Controller_DOC_RELEASE
Indicates that the source of the model control is the final close of the document. This is the very last controller used and only one until some document is opened again.
